A super efficient low emission fire can be built in to existing brick surrounds or add the optional Zero-Clearance Kit to build directly into timber framing without masonry
Nothing quite beats the clean lines and uncluttered look of an insert fire. No flue to look at, just an appliance on the wall surface. Clean, elegant and simple.
The Ares has all the intelligent combustion features, high output and and low fuel consumption of the freestanding models, with the benefit of discreet wall mounting.
Perfect if you have an existing open fire or log burner, the compact firebox design means there will be no trouble fitting into even the smallest open fireplaces, but don’t let the compact firebox size fool you. It can pump out a generous 14kW of heat, making it comparible to much larger rivals.
Add the extremely low emissions and high efficiency, and you’ll realise that you’re generating heat where other fires are just making smoke. Better for the environment, better for your wallet, and better for your home.
If you are building new, or renovating a home without an existing fireplace, just add in the optional Zero Clearance Kit to build your insert fire into timber framing and floors. The Ares gives maximum flexibility with minimum fuss, for the custom look you want.
Couple all this with the large entertaining viewing window, and the ability to choose from over 100 custom colours for the front facia and you have everything you need to stylishly heat your room.
Estimated Peak Output: 14kW
Average Efficiency: 67%
Average Emissions: 0.3 grams per kilogram
Emissions per Output : 22 milligrams per megajoule
Flue Diameter: 130mm
Fire Height: 600mm
Fire Width: 615mm
Fire Depth: 465mm
Facia Height: 650mm
Facia Width: 850mm
NZ MFE/ECAN approval number: 103880
Tested and compliant to the following standards:
- AS/NZS 4012:1999 Power output and heating efficiency
- AS/NZS 4013:1999 Flue gas emissions
- AS/NZS 2918:2001 Safety
- $2999 Ares fire
- $699 for 4.2m standard flue kit for existing masonry chimney*
- $899 for Zero Clearance Kit to build in to timber framing without masonry
- $999 for 4.2m Zero Clearance flue kit* (replaces standard flue kit in Zero Clearance installations)
- $699 for Zero Clearance Base (only required for timber floor installs)
* additional flue liners and hardware may be required for some installations. Please confirm with your Ethos dealer for total cost.
